Bateria iorn de lítio 51.2H LiFePo4 100ah 5kwh Pacote de bateria de lítio para armazenamento de energia doméstica

Armazenamento de energia doméstica 51,2H LiFePo4 iorn de lítio
  • Modelo:

    Off-Grid


Recurso:
Bom desempenho em alta temperatura
Tecnologia segura de fosfato de lítio e ferro
Alta densidade de energia e eficiência de conversão
Vida útil: 2.000 tempos de ciclo
Amigável ao meio ambiente, sem quaisquer metais pesados
Completo com sistema de gerenciamento de bateria integrado
Pode usar carregadores AC e solares para este sistema
Baixa taxa de autodescarga
Fácil instalação, pode ser em gabinete padrão ou na parede
Proteção automática integrada para sobrecarga, descarga excessiva & condições de superaquecimento
Densidade de alta energia 120-130kwh / kg, taxa de descarga mesmo alta, mantendo alta capacidade de energia.
Maior flexibilidade: o design modular permite a implantação
Boa alta taxa de descarga e excelente estabilidade
Design de chip inteligente, excelente capacidade de armazenamento da bateria

Formulários:

A bateria é aplicável para fins industriais, comerciais ou residenciais

Módulos ou unidades de bateria são conectados de Wh até Mwh para sistema de energia renovável

Sistema de armazenamento de energia

Armazenamento de energia solar

Iluminação Solar de Rua

Veículo Elétrico (EV)

Médico

Telecom

Robótica

UPS

Item
Especificação
Modelo
bateria de lítio
Voltagem
51,2 V
Capacidade nominal
100Ah (0,2C / 25 ° C) (Min: 98Ah)
Energia
4200wh
Faixa de tensão operacional
42V- 58,4V (típico: 51,2V)
Tensão de carga
56,0V ± 1,0V
Tensão de corte de descarga
42V ± 2,0V
Corrente de carga
20A
Corrente de carga (máx.)
30A
Corrente Contínua
50A
Corrente de descarga (máx.)
100A
Meses de auto-descarga
≤3,5%

Embalagem

lithium iron battery

Proejcts

lithium iron battery

produtos relacionados
Outdoor Cabinet Energy Storage System residential battery storage
Outdoor all-in-one ESS solution compatible with lithium battery storage residential battery storage, which used famous brand blade LiFePO4 battery module and original high voltage control box, comes with SNE 30KW or 50KW hybrid solar inverter. Easy to install and dispatch, with built-in HVAC/FSS (optional), and could be used in parallel on AC and/or DC. It is a compact and flexible ESS designed by SWT based on the characteristics of small C&I loads.
51.2V 100Ah LiFePO4 Battery
A sleek and space-saving solution for your energy storage needs. With its compact design and easy installation, it seamlessly blends into any environment. Whether in your home, office, or commercial space, our wall-mounted unit provides reliable and efficient energy storage,empowering you to optimize energy usage and reduce waste.
3.2V 228Ah Cell
The LiFePO4 Battery Cell is a high-performance, long-lasting, and versatile energy storage solution with advanced safety features. Specification Real Capacity:228Ah Nominal Voltage:3.2V Charge And Discharge Current:40A-200A Max Charge Voltage:3.65V AC Impedance Resistance:≤0.28mΩ Charging Temperature:0ºC~45ºC Discharge Working Temp:-20ºC~55ºC Cycle Life:≥6000 times Weight:4.22±0.1kg Dimensions (L*W*H):54*174*207mm
All-In-One Stackable  Battery
An efficient, safe, and intelligent home energy storage solution, featuring a convenient modular battery design and integrated inverter, EMS, and UPS management system. Seamlessly switch between power sources, remotely control your energy needs, and customize intelligent operating plans. It is a fully-integrated LiFePO4 battery system for residential usages. The system combines the most advanced battery management system with super power supply capacity to provide sustainable & green energy for your working and family usages all day.
solar 3KW -15KW system
PV Hybrid no sistema de grade solar 3KW -15KW
Solar Panels
Swt-power Solar is one of leading global manufacturers of solar modules and solar systems. With fully automated production line which ensures the quality is strict and stable. We can produce market mainstream solar modules, including large size, MBB, high efficient single glass and double glass modules both mono and poly, full cells and half cut cells. All our modules have TUV/CES/GSINMETRO/CQC/ISO9001/ISO14001 and  OHSAS18001 Certifications. Our solar modules have been exported to Europe, Vietnam, Brazil, Morocco and Many other markets.
3kw residential solar power system
gerador solar pode tecnicamente se referir a uma solução solar que combina uma estação de energia portátil com painéis solares. Ele converte a energia solar capturada por painéis solares em energia elétrica e a armazena em uma estação de energia portátil para uso posterior.
3.2V 304Ah Cell
The LiFePO4 Battery Cell is a high-performance, long-lasting, and versatile energy storage solution with advanced safety features. Specification Typical capacity:304.0 Ah @ 0.5C discharge Typical Voltage:3.2V Discharge current 0.5C with 2.5V cut off. (25±2)℃ AC Impedance Resistance:≤0.5mΩ Standard charge and discharge: Charge/Discharge Current 0.5C/1C Pulse Charge/Discharge Current (30s):2C/2C The maximum charge current of the battery does not exceed 1C under 0℃~45℃. Recommended SOC window:10%~90% Charging Temperature:0℃~60℃ Reference Continuous/Pulse Charge/Discharge Current Map Discharging Temperature:-30℃~60℃ Reference Continuous/Pulse Charge/Discharge Current Map Storage Temperature:- 20~45℃ Battery can work at a specified temperature range with capacity loss intolerance. Typical dimension:173.8*71.5*207.4mm Weight:5.49±0.3kg Cycle Life at 25℃:≥6000 cycles @250A/250A
